OVERVIEW

Sleek. Stylish. Smart.

The HG1J and HG2J, projected capacitive touch panel (PCAP) advanced technology—saves space while providing a smaller footprint and improves performance. These PCAP touch panels provide a high degree of visibility, durability, and functionality. In addition to being multi-touch, this PCAP touch panel is compatible with thin gloves.

Industrial Grade HMI Design

Extreme Operating Temperatures

-20 to 55°C, suitable for both hot and cold environments.

Long LED Backlight Life

Industry-leading 50,000 hours of backlight life ensures longevity.

Low Maintenance

Battery-free MRAM and hyper-capacitor design eliminates the need for battery replacements.

Reduced Power Consumption

Consumes approximately 40% less power than separate PLC and HMI combined.

Support Multi-Touch

PCAP touchscreens provide multi-touch capabilities and respond to a light touch without needing force.

Operates with or without Gloves

The touchscreen works seamlessly with gloves on or off, enhancing usability.

Waterproof/Oil Resistance

IP66F and IP67F ratings make these units suitable for wash-down applications and subject to oil spills.

Industry Leading Warranty

Built for endurance and backed by a three-year warranty.

Certifications

UL61010, UL Type 4X, 12, and 13, Class I Div 2 for hazardous locations.

Prevent Accidental Input Due to Water Droplets

Self-capacitance technology ensures that the touchscreen is not affected by water drops, preventing accidental inputs.

Compact, yet high performance

Highly visible glass-top structure

Easily kept clean using chemical washdown or simple wipes. Besides being water- and scratch-resistent, PCAP is responsive and provides high tolerance to resist false signals when dirt or water droplets are present on the face of the HMI.

No mechanical durability issues

The PCAP touch panel uses a sensor board to detect changes in electric charge to identify the position of the touch. There is no mechanical deterioration, allowing for agile operation, and multi-touch sensing gloves less than 1.5mm thick¹ can be used.

1. The touchscreen may not work with gloves less than 1.5mm thick depending on the material or environment. Check operation in the actual use environment or under similar conditions.

The tempered glass ensures high impact resistance. The HG1J and HG2J panels, protected by a safety film, successfully withstood a drop test involving a 1kg steel ball dropped from a height of 60cm onto the glass center. Even at an increased drop height of 80cm, where the glass may have cracked, the protective film effectively contained any shards, preventing them from scattering.

Water pressure test on tempered glass

Steel ball drop test on tempered glass (front of the panel)
(sample used: HG2J (the same panel and size as the FT2J))

Coin cell batteries not required

Battery-free design with data stored on nonvolatile magnetic media. Time information is preserved with power from large-capacity capacitors. ;Since lithium batteries are not consumable, they are not affected during ocean and air transportation and do not require maintenance for battery replacement, leading to reduced waste.

Optimizing Industrial Communication

FT2J-B700-HMI-PLC-1-pdf-09-23-2024_01_19_AM

IIOT Ready

Seamless Connectivity Solutions

EP1831-0-FT1J-FT2J-2-pdf-09-23-2024_01_23_AM

FTP Communication Protocol

FTP communication allows users to configure the HMI screen as a FTP Client or Server for transfer of programs and logged data between a Client and Server, providing a convenient and effective way to remotely communicate with the HMI.
Up to 16 Servers can be managed simultaneously, and access folders can also be managed.
This greatly simplifies User program updates, as it’s no longer necessary to have the IDEC programming software installed on multiple PCs throughout a facility or a company.

Email Function

Dynamic PLC and HMI values can ne incorporated into email to show status conditions. Files, such as Alarm Log, Data Log, Operation Log and Screenshot can be attached in the email. Up to 255 email templates can be configured to multiple recipients.

WindEdit Lite App

Available for FREE in the App Store or Google Play, this app provides quick and convenient remote monitoring and control from smartphones and tablets. Users can upload and download HMI Programs, monitor HMI device addresses, access logged data and manage files in SD/USB memory cards.

BACNet Protocol

BACNet is a communications protocol for building automation and control systems such as heating, and air-conditioning control (HVAC), lighting control, access control, and fire detection and their associated equipment.
Building Automation control protocol is now supported in the native Ethernet port of the HG1J and HG2J displays.

No HTML Programming Required

WindOI NV4 version 1.4.0 or later has a new Web Page Editor, making it simple to create professional and dynamic web pages to monitor and control an IDEC touchscreen, with no HTML programming required.

PART NUMBERS

HG-J Part Numbers

Interface	Part No.	Name
	HG1J-4FT22TG-B HG1J-4FT22TG-S	4.3 in PCAP Color HMI, Black Bezel 4.3 in PCAP Color HMI, Silver Bezel
	HG2J-7UT22TF-B	7 in PCAP Color HMI, Black Bezel
